Genisis RTF Pro

Genisis RTF Pro

£35,934.00 Regular Price
£29,500.00Sale Price

THE Genisis RTF Pro series of machine has premilling with diamond cutterheads along with top and bottom anti adhesive spray at the front of the machine, followed by preheating of the edge prior to reaching the gluepot.



The Teflon coated quick release gluepot has 2 independent temperature zones, one to the tank and one to the application roller with automatic lowering of the temperature when the machine is not in use. Heat up time is around 15 minutes.



The machine can process panels up to 60mm in thickness and has 2 x independent high frequency end trim saws, 2 x top and bottom high frequency flush trimmers, separate corner rounder, top and bottom profile scrapers with quick exclusion, top and bottom glue scrapers with quick exclusion, top and bottom polishing spray and top and bottom buffers.



The machine is operated via the 7” colour touchscreen and working at 10 m/min ensures efficiency and productivity for edging tape ranging from 0.4 to 3mm in thickness.

Genisis RTF Pro



Minimum working height

10mm

Maximum working height

60mm

Minimum length

120mm

Minimum width

100mm

Minimum thickness of edge

0.4mm

Maximum thickness of edge

3mm

Feed Speed

10 m/min

Anti  adhesive spray

Yes

First Pre milling Motor

1.5 Kw, 12,000 RPM

Second Pre Milling Motor

1.5 Kw, 12,000 RPM

Edge Pre Heating

Infra Red

Front and back trimming motor

2 x 0.22 Kw, 12,000 RPM

Top and Bottom trimming motor

2 x 0.55 Kw, 12,000 RPM

Corner rounding unit

1 x 0.55 Kw, 12,000 RPM

Top and Bottom profile scrapers

Quick exclusion

Top and bottom glue scrapers

Quick exclusion

Top and bottom polishing spray

Yes

Top and bottom buffers

2 x 0.18 Kw, 2,800 RPM

Dust extraction outlets

1 x 100mm dia + 3 x 120mm dia

Compressed air requirement

6.5 Bar

Total Installed Power requirement

6.9 Kw

Overall dimensions L x B x H

4100 x 1220 x 1686mm

Weight

1170 Kg
